Interior Drawing Services
Full CAD documentation for interior projects, from floor plans to wall elevations
Interior Drawings We Produce
You send us a design concept, a 3D model, or hand sketches, and we prepare accurate drawings for construction and installation.
- Floor plans with walls, furniture, and dimensions.
- Reflected ceiling plans with levels, materials, and fixtures.
- Lighting and electricity plans with fixtures, sockets, and switches.
- Plumbing plans with water supply and drainage points.
- Floor covering plans with materials and layout direction.
- Wall elevations with finishes, fixtures, and dimensions.
- Built-in elevations and sections for wardrobes, vanities, media walls and pantries.
- Finish and material schedules keyed to the plans, so every code on a sheet has an entry.
Here is a real set of interior drawings in PDF: download the example. To see what a good plan includes, read our guide on floor plan services.
Architectural Millwork Drawings
Wardrobes, vanities, media walls and pantries, drawn so a shop can build them
Millwork is where an interior design stops being a picture and becomes something a shop can build. We draft the joinery for every room in the set: wardrobes and walk-in closets, vanities and bathroom cabinetry, media walls, bedroom built-ins, pantries and kitchen units.
Each piece gets plan views, elevations, sections through the carcass and enlarged details of every junction, with hardware and finishes called out. The shop prices from those sheets and cuts from them, and the design keeps the look that was sold to the client.
Send a concept, a 3D model or photos of the space and we turn them into architectural millwork drawings at $20 per hour. If millwork is the whole job rather than part of an interior, start from our millwork shop drawing services.
